Flower Platycodon-1 Purple

Spectrum Details

Modality

NIR

Category

vegetation

Material Type

PLANT

Sample ID

Platycodon-1

Collection Locality

Lakewood, Colorado

Spectral Purity

1a2_3_4_ # 1= 0.2-3, 2= 1.5-6, 3= 6-25, 4= 20-150 microns

Composition / XRD

none

Sample Description

Average reflectance for a purple-blue flower of the platycodon plant (Platycodon sp.). The small flowers of the plant were 3-6 cm in diameter. The platycodon plant was growing in a domestic garden. The spectra were collected with the head of the spectrometer pointed approximately 45 degrees off-nadir, approximately 2-3 centimeters from the surface of the flower. The spectrometer head (bare fiber optic) was moved over different parts of the flower petals in order to compute the average reflectance for the flower from any variations in the individual petals. This average spectrum was computed from 11 individual recorded spectra (each recorded spectrum was an average of 60 measurements). Sky conditions during the measurement were cloud-free. IMAGE_OF_SAMPLE:

X Units

cm⁻¹

Y Units

Absorbance

Data Points

2,126
