Wollastonite

Spectrum Details

Modality

FTIR

Category

mineral

Material Type

Inosilicate

Sample ID

HS348.1B, HS348.2B, HS348.3B, HS348.4B

Collection Locality

Santa Fe Mine, Pichucalco, Chiapas, Mexico

Spectral Purity

1c2_3_4_ # HS348.1B # 1= 0.2-3, 2= 1.5-6, 3= 6-25, 4= 20-150 microns SPECTRAL_PURITY: 1c2_3_4_ # HS348.2B # 1= 0.2-3, 2= 1.5-6, 3= 6-25, 4= 20-150 microns SPECTRAL_PURITY: 1c2c3c4c # HS348.3B # 1= 0.2-3, 2= 1.5-6, 3= 6-25, 4= 20-150 microns SPECTRAL_PURITY: 1b2_3_4_ # HS348.4B # 1= 0.2-3, 2= 1.5-6, 3= 6-25, 4= 20-150 microns

Composition / XRD

EPMA # XRF, EPMA, ICP(Trace), WChem

Sample Description

"Results of petrographic examination: Single crystal 2 x 0.5 x 1 cm and one large piece 4 x 0.5 x 1. cm. One dirty surface and sulfide inclusions which were separated by crushing and hand picking. Under petrographic microscope, some grains show a little alteration and inclusions or voids along cleavage directions - possible exsolved pyroxene?" Salisbury, J. W., Walter, L. W., and Vergo, N., 1987, Mid-Infrared (2.1-25µm) Spectra of Minerals: First Edition, U.S. Geological Survey Open File Report 87-263. Grain size fractions are indicated by the extension after the sample number: .1B = IMAGE_OF_SAMPLE:

XRD Analysis

X-ray analysis indicates sample is pure. Salisbury, J. W., Walter, L. W., and Vergo, N., 1987, Mid-Infrared (2.1-25µm) Spectra of Minerals: First Edition, U.S. Geological Survey Open File Report 87-263.

X Units

cm⁻¹

Y Units

Absorbance

Data Points

1,801
